Horizontal multi-stage centrifugal pump

Product Features:

Corrosion Resistance: Core components of the pump body are made of high-quality 304 stainless steel;
Safety & Reliability: Equipped with an internal overheat protection device to prevent burnout and extend service life;
Pure Copper Motor: Strong power and stable operation;
Leakage Prevention: Dedicated mechanical seal to eliminate leakage;

Materials:

Pump body: Sus304, Impeller: Sus304, Guide;
vane: Sus304, Rotor shaft: 304ss + 45# steel;
Coil:Copper;

Motor:

Copper wire motor;
Maximum ambient temperature: 40℃;
Protection class: IPX4;
Insulation class: F;
Single-phase 220-240V/50Hz, 380V/50Hz
optional; 60Hz available

Usage Environment:

Suitable for the transfer of clean water or other liquids similar to clean water.
Applicable to domestic water supply, air conditioning systems, cooling systems, industrial cleaning, water treatment and other fields.
